Adjustable Positioner
General-purpose adjustable positioner (no specific contact list).
K1 (ref. M22520/2-02)
MS3192-20, MS3193-20
K330-3
SAE AS81511 Series 3; SAE AS81511 Series 1
M22520/2-04
MS18233-2; MS18233-1; MS18265-1… etc.
M22520/2-06
M38999 Series 2 — M39029/57-356 (22# socket), M39029/57-355 (22M# socket), M39029/57-354 (22D# socket)
M22520/2-07
M38999 Series 1 & 3 — M39029/56-350 (22# socket), M39029/56-349 (22M# socket), M39029/56-348 (22D# socket)
M22520/2-08
M24308 Series — M39029/63-968 (20# socket), M39029/64-369 (20# pin), M39029/63-928 (20# pin)
AS81659 & D-Sub — M39029/11-145 (20# pin), M39029/12-149 (20# socket), M39029/93-598 (20# pin), M39029/94-602 (20# socket)
M22520/2-09
MS27493-22 / 22M / 22D — M39029/90-529, M39029/91-530, M24308/13-1 Contacts
M22520/2-10
M38999 Series 1,3,4 — M39029/58-363 (20# pin), M39029/56-351 (20# socket)
M38999 Series 2 — M39029/57-357 (20# socket)
M22520/2-11
M39029/1-26-22; M39029/1-26-20; M39029/2-22; M39029/3-20; M39029/3-22
M22520/2-13
M39029/1-28-23; M39029/1-26-23; M39029/1-28-22
M22520/2-14
M39029/16-20-20; M39029/18-20-20
M22520/2-23
M39029/11-22-22; M39029/12-22-22
M22520/2-35
M39029/76; M39029/77; M39029/78
M22520/2-37
M39029/90-529; M39029/91-530; M39029/113-625 (8# pin), M39029/114-628 (8# socket), M39029/119 (8# pin), M39029/120 (8# socket)
