| Frequency |
11.303 GHz |
| Tuning Voltage |
1 - 12 VDC |
| Bias Voltage |
+7 VDC @ 25 mA (Max.) |
| Output Power |
0 dBm (Min.) |
| Tuning Sensitivity |
0.35 MHz/V (Typ.) |
| Thermal Drift |
2 ppm /°C (Typ.) |
| Output Impedance |
50 Ohms (Nom.) |
| Harmonic Suppression |
30 dBc (Typ.) |
| Frequency Pulling |
1.2 MHz (Typ. @ 1.75:1 VSWR) |
| Frequency Pushing |
1.6 MHz/V (Typ.) |
| Tuning Port Capacitance |
35 pF (Typ.) |
| Modulation Bandwidth |
> 20 MHz |
| Phase Noise |
@ 10 kHz: –106 dBc/Hz
@ 100 kHz: –130 dBc/Hz
@ 1 MHz: –150 dBc/Hz |
| Jitter |
93 fs (@ 1 kHz to 30 MHz) (Typ.) |
| Operating Temperature Range |
–15 to +75 °C |
| Absolute Maximum Ratings |
| Storage Temp. Range |
–30 to +85 °C |
| Bias Voltage |
+7.5 V |
| Tuning Voltage |
+16 V |
| DC Voltage Applied to RF Out |
±25 V |
