| Frequency |
1000 MHz |
| Tuning Voltage |
0.5 - 14 VDC |
| Bias Voltage |
+3 VDC @ 35 mA (Max.) |
| Output Power |
+3 dBm (Min.) |
| Tuning Sensitivity |
15 kHz/V (Typ.) |
| Output Impedance |
50 Ohms (Nom.) |
| Harmonic Suppression |
|
| Frequency Pulling |
13 kHz (Typ. @ 1.75:1 VSWR) |
| Frequency Pushing |
13 kHz/V (Typ.) |
| Tuning Port Capacitance |
35 pF (Typ.) |
| Typical Phase Noise |
| Offset |
dBc/Hz |
| @ 10 kHz |
-138 |
| @ 100 kHz |
-157 |
|
| Operating Temperature Range |
-20 to +70 °C |
