Product Features & Performance
|
| Standard |
Designed to MIL-R-6106 |
| Duty Type |
Type II unsealed continuous duty
Type III unsealed intermittent duty
|
| Contact Construction |
Covered / gasketed contact area
Twin-break silver alloy contacts
|
| Environmental Protection |
Meets explosion, humidity, salt spray, sand and dust requirements
|
| Altitude |
50,000 ft |
| Shock |
25 G (½ sine), 6-9 ms
Maximum contact opening: 2 ms
|
| Acceleration |
10 g |
| Vibration Limits |
5-10 Hz: 0.8 in da
10-55 Hz: 0.6 in da
55-2000 Hz: 2 g
|
| Temperature Range |
-55°C to +71°C |
| Insulation Resistance |
100 MΩ minimum initially
50 MΩ minimum after tests
|
| Dielectric Strength |
1250 VAC minimum initially
1000 VAC minimum after tests
|
| Electrical Life |
50,000 cycles |
| Mechanical Life |
100,000 cycles (at 25% rated resistive load)
|
| Minimum Current |
10% of rated DC resistive load
|
| Intermittent Duty |
% of rated resistive load
Time ON measured in minutes
Cooling time required between successive overload applications
|
