| Fundamental Frequency Output (RF1) |
120 MHz |
| Multiplied Frequency Output (RF2) |
240 MHz |
| External Reference Input |
10 MHz (≤500 ppb) |
| External Reference Level |
+1 to +13 dBm |
| Output Power (dBm) |
RF1 (120 MHz): +7 dBm (Min.)
RF2 (240 MHz): +11 dBm (Min.) |
| Harmonics |
–80 dBc (Max.) |
| RF2 Sub-Harmonic (120 MHz) |
–70 dBc (Max.) |
| Spurious |
–80 dBc (Max.) |
| Impedance (All Ports) |
50 Ohms |
| Loop Bandwidth |
5 Hz (Typ.) |
| Frequency Stability RF1 * RF2 (free-running) |
| Frequency Tolerance |
±100 ppb (Typ.), ±500 ppb (Max.) |
| Over Operating Temperature |
±100 ppb (Typ.), ±500 ppb (Max.) |
| Frequency Pushing (VS ±5%) |
±10 ppb (Max.) |
| Load Pulling (RL ±5%) |
±10 ppb (Max.) |
| Long Term Aging (per day) |
±1 ppb (Typ.), ±2 ppb (Max.) |
| Long Term Aging (1st year) |
±200 ppb (Typ.), ±500 ppb (Max.) |
| Long Term Aging (life) |
±100 ppb/yr (Typ.), ±200 ppb/yr (Max.) |
