| Frequency (Fo) |
25.6 GHz |
| Output Power |
≥ +13 dBm |
| Reference Input Frequency |
1280 MHz |
| Reference Input Level |
0 to +6 dBm |
| Supply Voltage |
Vcc (Vdc): +8 to +12
Icc (mA Max.): 700 |
| Harmonics (1.5×Fo) |
30 dB (Min.) |
| Sub-Harmonic (0.5×Fo) |
30 dB (Min.) |
| Output Spurious |
70 dB (Min.) |
| Reference Sideband1 |
63 dB (Min.) |
| Output Load Impedance |
50 Ohms (Nom.) |
| Typical Phase Noise |
@ 1 kHz: –108 dBc/Hz |
| @ 10 kHz: –118 dBc/Hz |
| @ 100 kHz: –123 dBc/Hz |
| @ 1 MHz: –133 dBc/Hz |
| @ 10 MHz: –151 dBc/Hz |
| Lock Detect Indicator |
CMOS High (Lock), CMOS Low (Lock) |
| Operating Temperature Range |
–20 to +50 °C |
| Storage Temperature Range |
–40 to +85 °C |
| ¹ Reference sidebands are measured at 25.6 GHz ±N × 1.28 GHz, where N = 1, 2. |
