| Frequency |
1500 MHz |
| Tuning Voltage |
0.5 - 12 VDC |
| Bias Voltage (Vcc) |
+5 VDC (± 5%) @ 100 mA (Max.) |
| Output Power |
+10 dBm (Min.) |
| Tuning Sensitivity |
30 kHz/V (Typ.) |
| Thermal Drift |
170 kHz (Typ.) |
| Output Impedance |
50 Ohms (Nom.) |
| Harmonic Suppression |
2nd: 16 dBc (Typ.) |
| 3rd: 25 dBc (Typ.) |
| Sub-Harmonic Suppression |
23 dBc (Typ.) |
| Frequency Pulling |
15 kHz (Typ. @ 1.75:1 VSWR) |
| Frequency Pushing |
20 kHz/V (Typ.) Vcc ±5% |
| Tuning Port Capacitance |
75 pF (Typ.) |
| Phase Noise @ 25 °C |
@ 10 kHz: -140 dBc/Hz |
| @ 100 kHz: -160 dBc/Hz |
| Operating Temperature Range |
-20 to +70 °C |
