| SPECIFICATION |
| Frequency |
2000 MHz |
| Reference Input Frequency |
100 MHz ± |
| Reference Input Voltage |
1.0 to 3.3 V p-p |
| Bias Voltage |
Digital: +5 V / 25 mA
Tune: +12 V / 10 mA
VCO: +5 V / 100 mA |
| Output Power |
+5 dBm (Min.) |
| Spurious Suppression |
80 dB (Typ.) |
| Harmonic Suppression |
20 dB (Typ.) |
| Sub-Harmonic Suppression |
20 dB (Nom.) |
| Output Impedance |
50 Ohms (Nom.) |
| Lock Detect Indicator |
CMOS 3.3 V |
| Typical Phase Noise |
@ 100 Hz: –80 dBc/Hz |
| @ 1 kHz: –105 dBc/Hz |
| @ 10 kHz: –135 dBc/Hz |
| @ 100 kHz: –158 dBc/Hz |
| @ 1 MHz: –165 dBc/Hz |
| Operating Temperature Range |
–20 to +70 °C |
| * External 100 MHz reference sources should have phase noise better than –138 dBc/Hz @ 50 Hz offset to achieve published specifications. |
| Absolute Maximum Ratings |
| Storage Temp. Range |
–40 to +85 °C |
| Bias Voltage (Digital) |
+5.25 V |
| Bias Voltage (Tune) |
+13.0 V |
| Bias Voltage (VCO) |
+5.5 V |
Patent: http://www.synergymwave.com/patents
