| Frequency |
6080 - 6340 MHz |
| Tuning Voltage |
See table below. |
| Bias Voltage |
+3 VDC @ 26 mA (Max.) |
| Output Power |
-6 dBm (Min.) |
| Tuning Sensitivity |
95 - 105 MHz/V (Typ.) |
| Output Impedance |
50 Ohms (Nom.) |
| Harmonic Suppression |
25 dB (Typ.) |
| Frequency Pulling |
30 MHz (Typ. @ 1.75:1 VSWR) |
| Frequency Pushing |
30 MHz/V (Typ.) |
| Tuning Port Capacitance |
1.5 pF (Typ.) |
| Typical Phase Noise |
| Offset |
dBc/Hz |
| 10 kHz |
-86 |
| 100 kHz |
-108 |
|
| Operating Temperature Range |
-40 to +85 °C |
