| Frequency |
128 MHz |
| Reference Input Frequency |
10 MHz1 |
| Reference Input Voltage |
1.0 to 3.3 V p-p |
| Bias Voltage (Vcc) |
+5 Vdc @ 85 mA (Max.) |
| Output Power |
8 dBm (Min.) |
| Modulation Bandwidth |
30 Hz (Typ.) |
| Harmonic Suppression |
20 dB (Typ.) |
| Output Impedance |
50 Ohms (Nom.) |
| Lock Detect Indicator |
LVCMOS 3.3 V
(logic: 1 = lock, 0 = unlock) |
| Typical Phase Noise |
@ 100 Hz: –100 dBc/Hz |
| @ 1 kHz: –130 dBc/Hz |
| @ 10 kHz: –155 dBc/Hz |
| @ 100 kHz: –160 dBc/Hz |
| Operating Temperature Range |
–40 to +85 °C |
| * External 10 MHz reference sources should have phase noise better than –138 dBc/Hz @ 50 Hz offset to achieve published specifications. |
