| SPECIFICATIONS (Rev. B 10/11/24) |
| Frequency |
7.92 GHz |
| Tuning Voltage |
1 - 10 VDC |
| Bias Voltage |
+5 VDC @ 12 mA (Max.) |
| Output Power |
0 dBm (Min.) |
| Tuning Sensitivity |
1.5 MHz/V (Typ.) |
| Thermal Drift |
2.1 ppm / °C (Typ.) |
| Output Impedance |
50 Ohms (Nom.) |
| Harmonic Suppression |
45 dBc (Typ.) |
| Frequency Pulling |
1 MHz (Typ. @ 1.75:1 VSWR) |
| Frequency Pushing |
85 MHz/V (Typ.) |
| Tuning Port Capacitance |
10 pF (Typ.) |
| Phase Noise @ 25°C |
| @ 10 kHz |
-112 dBc/Hz |
| @ 100 kHz |
-134 dBc/Hz |
| @ 1 MHz |
-153 dBc/Hz |
| @ 10 MHz |
-155 dBc/Hz |
| Operating Temperature Range |
-40 to +85 °C |
| Absolute Maximum Ratings |
| Storage Temp. Range |
-45 to +90 °C |
| Bias Voltage |
+8.5 V |
| Tuning Voltage |
+16 V |
| DC Voltage Applied to RF Out |
±25 V |
