| SPECIFICATIONS (Rev. D 04/08/11) |
| Frequency |
3970 - 6970 MHz |
| Step Size |
1000 kHz |
| Reference Input Frequency |
10 MHz |
| Reference Input Voltage |
1 V p-p to 3.3 V p-p |
| Bias Voltage |
| Vcc (VCO) |
+5 V / 55 mA |
| Digital |
+5 V / 60 mA |
| Converter |
+8 V / 25 mA |
| Output Power |
+4 dBm (Min.) |
| Spurious Suppression |
65 dB (Typ.) |
| Harmonic Suppression |
18 dB (Typ.) |
| Setting Time |
10 mSec (Typ.) |
| Output Impedance |
50 Ohms (Nom.) |
| Lock Detect Indicator |
CMOS 3.3 V |
| Typical Phase Noise |
| @ 1 kHz |
-78 dBc/Hz |
| @ 10 kHz |
-80 dBc/Hz |
| @ 100 kHz |
-100 dBc/Hz |
| Operating Temperature Range |
-30 to +70 °C |
| Programming |
| See Application Note: AN7100 |
| * Reference input frequency is programmable (see AN7100) in multiples of the step size. 10 MHz is the factory default setting. 150 MHz (Max.) |
| ² From the rising edge of LE to stable lock detect |
| Absolute Maximum Ratings |
| Storage Temp. Range |
-55 to +125 °C |
| Bias Voltage (Digital) |
+5.25 V |
| Bias Voltage (VCO) |
+5.5 V |
| Bias Voltage (Converter) |
+8.5 V |
| DC Voltage Applied to RF Out |
±25 V |
