| Frequency (Fo) |
27.5 GHz |
| Output Power |
≥ 8 dBm |
| Reference Input Frequency |
100 MHz |
| Reference Input Level |
–3 to +3 dBm |
| Supply Voltage |
Vcc (Vdc): +12
Icc (mA Max.): 400 |
| Harmonics (2×Fo) |
25 dBc (Min.) |
| Sub-Harmonic (3×Fo) |
27 dBc (Min.) |
| Output Spurious |
60 dBc (Min.) |
| Reference Sideband |
60 dBc (Min.) |
| Output Load Impedance |
50 Ohms (Nom.) |
| Typical Phase Noise |
@ 1 kHz: –85 dBc/Hz |
| @ 10 kHz: –88 dBc/Hz |
| @ 100 kHz: –98 dBc/Hz |
| @ 1 MHz: –112 dBc/Hz |
| @ 10 MHz: –145 dBc/Hz |
| Lock Detect Indicator |
CMOS High (Lock), CMOS Low (Unlock) |
| Operating Temperature Range |
–20 to +50 °C |
| Storage Temperature Range |
–40 to +85 °C |
| * Requires adequate heat sinking to avoid exceeding the maximum operating temperature. |
