| Frequency |
800 MHz |
| Tuning Voltage |
0.5 - 12 VDC |
| Bias Voltage (Vcc) |
+5 VDC (± 5%) @ 20 mA (Max.) |
| Output Power |
+3 dBm (Min.) |
| Tuning Sensitivity |
18 kHz/V (Typ.) |
| Thermal Drift |
80 kHz (Typ.) |
| Output Impedance |
50 Ohms (Nom.) |
| Harmonic Suppression |
|
| Frequency Pulling |
10 kHz (Typ. @ 1.75:1 VSWR) |
| Frequency Pushing |
5 kHz/V (Typ.) Vcc ± 5% |
| Tuning Port Capacitance |
125 pF (Typ.) |
| Phase Noise @ 25 °C |
| Offset |
dBc/Hz (Typ.) |
| @ 10 kHz |
-146 |
| @ 100 kHz |
-164 |
|
| Operating Temperature Range |
-20 to +70 °C |
