| Frequency |
2000 MHz |
| Tuning Voltage |
0.5 - 12 VDC |
| Bias Voltage (Vcc) |
+5 VDC (±5%) @ 100 mA (Max.) |
| Output Power |
+6 dBm (Min.) |
| Tuning Sensitivity |
35 kHz/V (Typ.) |
| Thermal Drift |
300 kHz (Typ.) |
| Output Impedance |
50 Ohms (Nom.) |
| Harmonic Suppression |
2nd: 20 dBc (Typ.) |
| 3rd: 20 dBc (Typ.) |
| Sub-Harmonic Suppression |
20 dBc (Typ.) |
| Frequency Pulling |
15 kHz (Typ. @ 1.75:1 VSWR) |
| Frequency Pushing |
20 kHz/V (Typ.) Vcc ±5% |
| Tuning Port Capacitance |
55 pF (Typ.) |
| Phase Noise @ 25°C |
@ 10 kHz: -133 dBc/Hz (Typ.) |
| @ 100 kHz: -159 dBc/Hz (Typ.) |
| — |
| Operating Temperature Range |
-20 to +70 °C |
