| Frequency |
1000 MHz |
| Tuning Voltage |
0.5 - 12 VDC |
| Bias Voltage |
+5 VDC (±5%) @ 35 mA (Max.) |
| Output Power |
+2 dBm (Min.) |
| Tuning Sensitivity |
20 kHz/V (Typ.) |
| Thermal Drift |
110 kHz (Typ.) |
| Output Impedance |
50 Ohms (Nom.) |
| Harmonic Suppression |
2nd: 35 dBc (Typ.) |
| 3rd: 25 dBc (Typ.) |
| Frequency Pulling |
10 kHz (Typ. @ 1.75:1 VSWR) |
| Frequency Pushing |
20 kHz/V (Typ.) Vcc ±5% |
| Tuning Port Capacitance |
130 pF (Typ.) |
| Phase Noise @ 25 °C |
@ 10 kHz: -144 dBc/Hz |
| @ 100 kHz: -162 dBc/Hz |
| Operating Temperature Range |
-20 to +70 °C |
