| SPECIFICATIONS (Rev. E 04/22/16) |
| Frequency |
8800 - 9200 MHz |
| Tuning Voltage |
See table below. |
| Bias Voltage |
+5 VDC @ 26.4 mA (Max.) |
| Output Power |
+0 dBm (Min.) |
| Tuning Sensitivity |
90 - 160 MHz/V (Typ.) |
| Output Impedance |
50 Ohms (Nom.) |
| Harmonic Suppression |
10 dB (Typ.) |
| Frequency Pulling |
25 MHz (Typ. @ 1.75:1 VSWR) |
| Frequency Pushing |
12 MHz/V (Typ.) |
| Tuning Port Capacitance |
1.5 pF (Typ.) |
| Phase Noise @ 10 kHz |
-80 dBc/Hz (Typ.) |
| Operating Temperature Range |
-40 to +85 °C |
