| SPECIFICATIONS (Rev. D 10/09/15) |
| Frequency |
10500 - 11000 MHz |
| Tuning Voltage |
0.5 to 15 V |
| Bias Voltage |
+5 VDC @ 25 mA (Max.) |
| Output Power |
+2 dBm (Min.) |
| Tuning Sensitivity |
40 - 68 MHz/V (Typ.) |
| Output Impedance |
50 Ohms (Nom.) |
| Harmonic Suppression |
22 dB (Typ.) |
| Frequency Pulling |
20 MHz (Typ. @ 1.75:1 VSWR) |
| Frequency Pushing |
10 MHz/V (Typ.) |
| Tuning Port Capacitance |
2 pF (Typ.) |
| Phase Noise @ 10 kHz |
-82 dBc/Hz (Typ.) |
| Operating Temperature Range |
-40 to +85 °C |
