Product Attribute
|
Attribute Value
|
|
Manufacturer:
|
TE Connectivity
|
|
Product Category:
|
Automotive Connectors
|
|
RoHS:
|
Details
|
|
Product:
|
Connectors
|
|
Number of Positions:
|
3 Position
|
|
Pitch:
|
10.01 mm
|
|
Gender:
|
Receptacle (Female)
|
|
Mounting Style:
|
Cable Mount / Free Hanging
|
|
Termination Style:
|
Crimp
|
|
Wire Gauge Min:
|
20 AWG
|
|
Wire Gauge Max:
|
14 AWG
|
|
Color:
|
Gray
|
|
Series:
|
DT
|
|
Tradename:
|
DT
|
|
Attachment Hole Diameter:
|
1.5 mm
|
|
Brand:
|
TE Connectivity / DEUTSCH
|
|
Contact Gender:
|
Without Pin Contacts
|
|
Current Rating:
|
13 A
|
|
Height:
|
24.71 mm
|
|
Housing Material:
|
Polyamide (PA)
|
|
Ingress Protection:
|
IP68, IP6K9K
|
|
Insulation:
|
Insulated
|
|
Length:
|
44.65 mm
|
|
Material:
|
Plastic
|
|
Mating Gender:
|
Plug
|
|
Mating Part Number:
|
DT06-3S
|
|
Maximum Operating Temperature:
|
+ 125 C
|
|
Minimum Operating Temperature:
|
- 55 C
|
|
Mounting Angle:
|
Straight
|
|
Product Type:
|
Automotive Connectors
|
|
Subcategory:
|
Automotive Connectors
|
|
Type:
|
3-Way
|
|
Voltage Rating:
|
250 V
|
|
Width:
|
21.13 mm
|
|
Wire Gauge Range:
|
14 AWG to 20 AWG
|
|
Part # Aliases:
|
DT04-3P-P007-AS 5-1899776-8 ZPF000000000130224
|
|
Unit Weight:
|
21,500 g
|
