Product Attribute
|
Attribute Value
|
|
Manufacturer:
|
TE Connectivity
|
|
Product Category:
|
Automotive Connectors
|
|
Product:
|
Connectors
|
|
Number of Positions:
|
2 Position
|
|
Pitch:
|
5.46 mm
|
|
Gender:
|
Receptacle (Female)
|
|
Mounting Style:
|
Cable Mount / Free Hanging
|
|
Termination Style:
|
Crimp
|
|
Wire Gauge Min:
|
20 AWG
|
|
Wire Gauge Max:
|
14 AWG
|
|
Color:
|
Gray
|
|
Packaging:
|
Bulk
|
|
Application:
|
Wire to Wire
|
|
Attachment Hole Diameter:
|
1.5 mm
|
|
Contact Gender:
|
Without Pin Contacts
|
|
Current Rating:
|
13 A
|
|
Height:
|
17.02 mm
|
|
Housing Material:
|
Polyamide (PA)
|
|
Ingress Protection:
|
IP68, IP6K9K
|
|
Length:
|
43.38 mm
|
|
Locking Mechanism:
|
Integrated in Housing
|
|
Material:
|
Plastic
|
|
Maximum Operating Temperature:
|
+ 125 C
|
|
Minimum Operating Temperature:
|
- 55 C
|
|
Mounting Angle:
|
Straight
|
|
Type:
|
Receptacle
|
|
Voltage Rating:
|
250 V
|
|
Width:
|
17.15 mm
|
|
Wire Gauge Range:
|
14 AWG to 20 AWG
|
|
Part # Aliases:
|
DT04-2P-L DT04-2P-LD DT04-2P-LS ZPF000000000130153
|
