| Frequency |
10.24 GHz |
| Tuning Voltage |
1 - 15 VDC |
| Bias Voltage |
+7 ~ +10 VDC @ 70 mA (Max.) |
| Output Power |
+7 dBm (Min.) |
| Tuning Sensitivity |
0.4 MHz/V (Typ.) |
| Thermal Drift |
2 ppm / °C (Typ.) |
| Output Impedance |
50 Ohms (Nom.) |
| Harmonic Suppression |
40 dBc (Typ.) |
| Tuning Port Capacitance |
1 nF (Typ.) |
| Modulation Bandwidth |
20 MHz (Typ.) |
| Phase Noise |
| Offset |
dBc/Hz (Typ.) |
| 1 kHz |
-79 |
| 10 kHz |
-109 |
| 100 kHz |
-136 |
| 1 MHz |
-158 |
| 10 MHz |
-170 |
|
| Jitter |
53 fs (@ 1 kHz to 30 MHz) (Typ.) |
| Operating Temperature Range |
-15 to +75 °C |
| Absolute Maximum Ratings |
| Storage Temp. Range |
-30 to +85 °C |
| Bias Voltage |
+10.5 V |
| Tuning Voltage |
+16.0 V |
| DC Voltage Applied to RF Out |
±25 V |
