| SPECIFICATIONS (Rev. D 03/06/23) |
| Frequency: |
8000 - 16000 MHz |
| Tuning Voltage: |
0.5 - 15 V |
| Bias Voltage (Vcc 1)*: |
-1.7 VDC @ 5 mA (Typ.) |
| Bias Voltage (Vcc 2): |
+5 VDC @ 190 mA (Max.) |
| Output Power: |
-1 dBm (Min.) |
| Tuning Sensitivity: |
300 - 900 MHz/V (Typ.) |
| Output Impedance: |
50 Ohms (Nom.) |
| Harmonic Suppression: |
17 dB (Typ.) |
| Sub-Harmonic: |
10 dB (Typ.) |
| Frequency Pulling: |
100 MHz (Typ. @ 2:1 VSWR) |
| Frequency Pushing: |
25 MHz/V (Typ.) |
| Tuning Port Capacitance: |
62 pF (Typ.) |
| Typical Phase Noise |
| Offset |
dBc/Hz |
| 10 kHz |
-67 |
| 100 kHz |
-94 |
|
| Operating Temperature Range: |
-40 to +85 °C |
Notes:
* Follow bias voltage sequencing
1) Set Vcc1 & Vcc2 to zero volts.
2) Set Vcc1 (gate voltage) as specified above.
3) Set Vcc2 (drain voltage) as specified above.
Typical plots are not indicative of actual performance. |
