Name: DCRO640675-8
Brand: SYNERGY
SKU: 0006000
Price: 360 USD
Availability: OutOfStock

DCRO640675-8

$ 300,00 + KDV

SPECIFICATIONS (Rev. B 01/09/12)
Frequency	6400 - 6750 MHz
Tuning Voltage	See table below.
Bias Voltage	+8 VDC @ 27 mA (Typ.)
Output Power	0 dBm (Min.)
Tuning Sensitivity	42 - 52 MHz/V (Typ.)
Thermal Drift	2 ppm / °C (Typ.)
Output Impedance	50 Ohms (Nom.)
Harmonic Suppression	20 dBc (Typ.)
Frequency Pulling	20 MHz (Typ. @ 1.75:1 VSWR)
Frequency Pushing	10 MHz/V (Typ.)
Tuning Port Capacitance	12 pF (Typ.)
Phase Noise @ 10 kHz	-85 dBc/Hz (Typ.)
Operating Temperature Range	-40 to +85 °C
Guaranteed Tuning Specifications
Tuning Voltage (V)	Frequency (MHz)
0.5	6400 (Max.)
5	6450 (Min.)
8	6600 (Min.)
12	6750 (Min.)
Absolute Maximum Ratings
Storage Temp. Range	-55 to +125 °C
Bias Voltage	+8.5 V
Tuning Voltage	+12 V
DC Voltage Applied to RF Out	±25 V
